Wall-Mount

Wall-Mount

Power range starting from 6W-30W with fixed plugs or interchageable plugs, also have the latest ITE or Medical safety approvals, and accept customized cables

ITE/Industrial Fix Plug Adapter

Model Power Input Voltage Output Voltage Features Dimensions (Inch)
    TRE06 6W 90-264 5V, 9V, 12V, 15V Cost Effective 2.047x1.417x0.992
    TRE15 15W 90-264 5V, 9V, 12V, 15V, 24V Cost Effective
Altitude 5000m
2.795x1.906x1.299
    TRG15 15W 90-264 5V, 6V, 7.5V, 9V, 12V, 13.6V, 15V, 18V, 24V Altitude 5000m
2.835x2.047x1.378
    TRE25 25W 90-264 5V, 9V, 12V, 15V, 18V, 24V Cost Effective 2.795x1.906x1.299

ITE/Industrial Interchangeable Plug Adapter

Model Power Input Voltage Output Voltage Features Dimensions (Inch)
    TRG10R 10W 90-264 5V, 5.9V, 6V, 7.5V, 9V, 12V, 13.6V, 15V, 18V, 24V Level VI Efficiency 2.858x1.823x1.402
    TRE15R 15W 90-264 5V, 9V, 12V, 15V, 24V Cost Effective
Altitude 5000m
2.795x2.220x1.299
    TRE15RD 15W 90-264 5V, 9V, 12V, 15V, 24V Cost Effective
Altitude 5000m
2.835x2.244x1.299
    TRE25R 25W 90-264 5V, 9V, 12V, 15V, 18V, 24V Cost Effective 2.795x2.220x1.299
    TRE25RD 25W 90-264 5V, 9V, 12V, 15V, 18V, 24V Cost Effective 2.835x2.244x1.299
    TRG30RV 30W 90-264 5V, 9V, 12V, 15V, 18V, 24V Altitude 5000m 4.243x2.267x1.319
    TRG30RAV 30W 90-264 5V, 9V, 12V, 15V, 18V, 24V Altitude 5000m
4.278x2.440x1.445

Medical Class II Interchangeable Plug Adapter

Model Power Input Voltage Output Voltage Features Dimensions (Inch)
    TR15RAM 15W 90-264 5V, 12V, 15V, 24V 2 MOPP
3.173x1.885x1.704
    TR18RDM 18W 80-264 5V, 9V, 12V, 15V, 18V, 24V 2MOPP
Altitude 5000m
EN60601-1-11 IP22,
Meets EN60335-1
3.165x1.693x1.453
    TR30RAM 30W 90-264 5V, 9V, 12V, 15V, 18V, 24V 2 MOPP
4.278x2.440x1.445
    TR30RDM 30W 80-264 5V, 9V, 12V, 15V, 18V, 24V 2MOPP
Altitude 5000m
EN60601-1-11 IP22
Meets EN60335-1
3.807x2.283x1.703
